General Specifications
| Voltage Range | 12 & 24v dc (48v also available) | |||
| Power Output Range | 150 to 300 watts | |||
| Speed Range | up to 9,000rpm | |||
| Operational Temperature | -20°C to +40°C | |||
| Insulation Class | F(consult us for class B) | |||
| Bear Type | High quality ball bearings | |||
| Housing Type | Closed(ventilated also available) | |||
Performance Data
| Model | Voltage | Rated Power | Rated Speed | Rated Torque | Rated Current | No load Speed | Length |
|---|---|---|---|---|---|---|---|
| Units | V | W | rpm | mNm | A | rpm | mm |
| 90ZYT155-12V | 12 | 250 | 4750 | 400 | 23 | 5540 | 155 |
| 90ZYT199-12V | 12 | 150 | 1200 | 1200 | 23 | 1500 | 199 |
| 90ZYT155-24V | 24 | 250 | 4750 | 500 | 13.8 | 5100 | 155 |
| 90ZYT199-24V | 24 | 150 | 1200 | 1200 | 11.5 | 1600 | 199 |
