General Specifications
| Voltage Range | 12 & 24v dc (48v also available) | |||
| Power Output Range | 90 to 150 watts | |||
| Speed Range | up to 9,000rpm | |||
| Operational Temperature | -20°C to +40°C | |||
| Insulation Class | F(consult us for class B) | |||
| Bear Type | High quality ball bearings | |||
| Housing Type | Closed(ventilated also available) | |||
Performance Data
| Model | Voltage | Rated Power | Rated Speed | Rated Torque | Rated Current | No load Speed | Length |
|---|---|---|---|---|---|---|---|
| Units | V | W | rpm | mNm | A | rpm | mm |
| 80ZYT122-12V | 12 | 54 | 1200 | 430 | 7.1 | 1600 | 122 |
| 80ZYT122-24V | 24 | 54 | 1200 | 430 | 3.5 | 1600 | 122 |
| 80ZYT122-40V | 40 | 54 | 1200 | 430 | 2 | 1600 | 122 |
| 80ZYT135-12V | 12 | 106 | 2900 | 350 | 11.5 | 3200 | 135 |
| 80ZYT135-24V | 24 | 106 | 2900 | 350 | 5.8 | 3200 | 135 |
| 80ZYT135-40V | 40 | 128 | 3500 | 350 | 4 | 3750 | 135 |
| 80ZYT175-12V | 12 | 207 | 3200 | 620 | 10 | 3500 | 175 |
| 80ZYT175-24V | 24 | 201 | 3100 | 620 | 6 | 3500 | 175 |
| 80ZYT175-40V | 40 | 221 | 3350 | 630 | 4.2 | 3650 | 175 |
